Soaking Pit Cable (SKPT) 600V 200 Deg.C

Our Soaking Pit Cables are designed for installation on overhead cranes, in steel mills, smelters, refineries or wherever unusually long service life is required under extreme heat and flexing conditions.

SKPT Cables offer reliable service in reeling/unreeling applications and are ideal for installation on electrically driven cable reels, heavy duty festooning applications, and other industrial applications which require a cable to perform under severe stress, heat, flexing and where molten metal spills may occur.

The use of a special Silicone Rubber Insulation compound allows continuous operation at 200 Deg. C.

Also, Silicone Rubber offers excellent chemical resistance and electrical properties, and when burnedSilicone Rubber leaves a non-conductive ash which retains excellent dielectric integrity, allowing continued operation until a controlled shutdown is possible.

Silicone Rubber is fungus resistant, has good weathering, flame, ozone and corona resistance, and produces minimal smoke emission when burned.

The insulated conductors are covered with a tightly braided glass yarn and are cabled together with non-wicking fillers and then covered overall with a K-Fibre (polyamide fibre braid *Kevlar) and finally an Overall Stainless Steel Braid for improved abrasion resistance.

Sizes in Stock : 12 AWG 4/C   12/7   10/4   8/4  6/2  6/4   4/4   2/4

W2A_Mining-Welding

FG 2000

12/2,  12/4 shielded, 14/12, 14/3, 16/2, 16/3, 16/3 shielded, 16/4, 18/2, 18/3 shielded, 18/4 shielded, 4/1

Available from Stock for immediate shipment.

FG2000

SRGK Cable

Silicone Rubber Glass Braid – Conductors with an overall Aramid Fiber Jacket
600 Volts, 200 Degrés Celsius, #16 AWG – #10 AWG

srkg



Temperature Ratings

Deg. CDeg. F
1540*FG20002800
538*MG (Micamat)1000
250SGI, TCGT, TGGT482
200SEW2, SRKX, KGXN, Teflon392
150SEWF2, TEFZEL302
125CL1251, CL1503, (EPDM) GEXOL, EXANE, GTF257
105TEW, CL1053 (CPE)221
90SIS, TBS, T90, PPC194
*CSA & UL 450 Deg. C.

FG2000 28 Minutes Circuit Integrity @ 1540 Deg.C. CSA 450 Deg.C. FT4
